  • It definitely depends on the circumstances. With 60 GHz radar e.g. you get quite a good distance resolution and can detect e.g. breathing rate really well (from the torso movement during breathing) and things like how many people are in a room, etc. But its always very dependent on the environment, your settings, subjects, noise, whatever. That’s why I said its typically not practical. By using dedicated devices perhaps, and most of these kinds of news are about people who use dedicated devices, but that’s like putting a camera in your home. When you have to abuse an existing communication channel, probably not so realistic.


  • My topic was fall detection (as in elderly people falling) specifically without using cameras or wearables. The idea was to take the CSI (basically what you see in the image) and just stuff it into some machine learning model to get a prediction as to whether someone fell in a given time frame, so I was trying to classify the signature of the falling “activity”. From my literature survey, this has been done successfully with CSI. But as with a lot of research, it typically lacked practicality. Much of my work was implementing the firmware, data recording, processing, and so on. I also had to record a ton of falls (ouch) and label them. I ended up throwing away the CSI approach though, because of the noise reasons I mentioned. That was simply a deal breaker. I went with FMCW radar instead (and it worked pretty good).



  • to be fair, maybe. To pass FCC/CE regulation regarding EMC, it has to adhere to strict limits at 2.4 GHz (but I could also imagine for microwave ovens specifically that the allowed emissions are higher than for other devices, because 2.4 GHz is just the band it operates in. But idk, I didnt read the standard for those). But it does not mean that it may not radiate anything in that band.

    Anyways, my observation was that it did interfere and the microwave was definitely closed. But also it was not 10m distance to the microwave, more like 2m, so relatively close. WiFi receivers are quite sensitive to be able to work with low received powers. So just a little emission is sufficient to interfere. You are probably not disturbing the communication itself, because OFDM is quite robust, but it certainly destroyed my use case (which operated on the whole CSI).

    And there is definitely some stuff leaking, e.g. through radiated emissions on the wiring (the power line). But it is certainly not cooking anything. That’s also what the regulation makes sure of.


  • I think the main advantage with the wifi-based approaches is that they are usually used in a relatively static/calm indoor environment with a stable channel response and your motions are disturbing that, compared to a quickly changing outdoor environment (e.g. a city) where it would be much harder to distinguish individuals. Also, you are typically closer to the access points, making the power/SNR higher. Regarding mobile communication though, the trend is towards higher frequencies and smaller cell sizes which also give greater spatial resolution (and higher power) and some funky near-field effects can be used to get beam forming on crack: https://arxiv.org/abs/2407.10147 So perhaps it could work even better, wouldn’t be surprised



  • That’s using CSI though. The article said the researches specifically did not utilize CSI.

    But regarding CSI: I evaluated that as a small part of my Master’s thesis and it worked pretty OK for motion detection but not for classifying other activities, at least not on a SISO link. For more complex stuff you would need both a MIMO access point (router) and device (e.g. phone). Also, you need to constantly transmit messages to get up-to-date CSI, which is not great for power consumption as well as cluttering the communication channel. There are some other constraints, especially regarding noise. E.g. I managed to completely destroy the CSI spectrogram by turning on a microwave oven. There is 802.11bf in development, which is supposed to standardize this, because currently using CSI is pretty much a “hack”, as it is not intended for sensing. Once this is widely adopted, I would start being worried, but not right now.

    This is from my thesis:






  • fleck@lemmy.worldtoScience Memes@mander.xyzControl theory
    link
    fedilink
    English
    arrow-up
    4
    ·
    2 months ago

    PIDs for can be very fun. And essentially its just 5 or so lines of code, which is something I wish they told us in uni (instead, it was mostly theory, as in the meme). I recently built a kiln which goes to 1000-something °C with a PID controller and I just set the parameters by vibes, not even some formal method. And it just works. So here is my resource: The (bit messy) controller code for my oven The code is obviously a bit more than those few lines, but I just wanted to say that the implementation is very simple, which I would have liked to know when I started out with this.

    Edit: just found a bug after looking at the code again haha, so thank you :D








  • Absolutely! These are the obvious ones, maybe you already know them:

    • T-Square
      • “TRUTH” is an absolute classic, just like “サーキットの放浪者”, and “Travellers”
    • Casiopea
      • I think “Be” is my favourite Album, but all are solid
    • Masayoshi Takanaka

    And then also some that are maybe lesser known (no particular order):

    • Katsumi Horii Project
      • They have quite a lot of songs. “Way to morning” or “Flashback” are good examples. I also like “Jungle of Heaven”
    • Trix
      • “ECCENTRIX” is really nice, just like “An Index”
    • Dimension
    • Himiko Kikuchi
    • Naniwa Express
    • Yuji Toriyama
    • Chikara Ueda & The Power Station
    • Toshiki Kadomatsu
    • The Gran Turismo soundtrack also has some hidden Gems here and there

    I think what I like about this genre is that it combines very catchy melodies/riffs and chord progressions with really creative jazzy solos. I have not really found much recent stuff (>2010), though. But I can recommend SOIL & Pimp Sessions. They are more recent and more traditional-jazz-oriented.

    Bonus if you like light prog/math rock: Check out Elephant Gym. Spring Rain (春雨) is one of my favourite songs.
